Belimo F6125HD+PKRXUP-MFT-T : 2-Way 5" Inch Butterfly Valve, ANSI Class 125, Cv 1022 + Electronic Fail-Safe Actuator, 24 to 240 VAC / 24 to 125 VDC, Programmable (2-10VDC Default) Control, 2x Aux. Switches, Terminal Strip, NEMA 4X, 5-Year Warranty
Belimo F6125HD resilient seated butterfly valve assembly with PKRXUP-MFT-T actuator provides dependable flow control for chilled water and hot water HVAC hydronic systems. The electronic fail-safe actuator supports modulating control and common building automation sequences. Use the specifications below to confirm pressure class, Cv, voltage, control signal, and enclosure rating before ordering.
Belimo F6125HD Valve Specifications
-
ANSI Class Consistent with 125 Pattern 2-way Cv 1022 Fluid Chilled or hot water, up to 60% glycol Body Pressure Rating ANSI Class Consistent with 125, 232 psi CWP Flow characteristic {Tools} Modified equal percentage End Fitting Flange Valve Size 5" [125] Belimo PKRXUP-MFT-T Valve Actuator Specifications
-
Voltage AC/DC AC 24...240 V / DC 24...125 V Power Consumption (Running) 52 W Power Consumption (Holding) 9 W Power Consumption For Wire Sizing with 24 V 54 VA / with 240 V 68 VA Auxiliary Switches 2x SPDT Control Type BACnet MS/TP Modbus RTU MP-Bus DC 2...10 V DC 0.5...10 V Degree Of Protection NEMA NEMA 4X Enclosure Type UL Enclosure Type 4X
Datasheets
- Valve Pattern:
- 2-Way
- Valve Size:
- 5 Inch
- ANSI Class:
- Consistent with 125
- CV Rating:
- 1022
- Actuator Type:
- Electronic Fail-Safe
- Voltage:
- 24 to 240 VAC / 24 to 125 VDC
- Control Signal:
- Modulating/Programmable
