AccuEnergy ACUREV-1314-333-X0 : AcuRev 1314 DIN Rail Power & Energy Meter (4 Current Inputs (Neutral)), 10-690Vac, 333mV CT Input, RS-485 Modbus RTU/BACnet MS/TP, Revenue Grade 0.5 Class, No Relay Output
The AccuEnergy ACUREV-1314-333-X0 is an AcuRev 1314 DIN rail power and energy meter designed for cost-effective electrical submetering in commercial and industrial facilities. It features a built-in LCD for quick setup and data access, wide 10-690Vac direct voltage input, and revenue-grade accuracy (IEC 62053-22 Class 0.5s / ANSI C12.20 Class 0.5). The meter supports 333mV CT Input, RS-485 communications (Modbus RTU or BACnet MS/TP), and pulse output integration. Base model (no relay output). Four current input channels support neutral current measurement.
Common Applications
- Energy management systems
- Large commercial complexes
- Industrial environments
- Hospitality and hotels
- Multi-tenant commercial or residential
- Schools and universities
- Smart distribution cabinets
Specifications
- Accuracy: IEC 62053-22 Class 0.5s; ANSI C12.20 Class 0.5
- Voltage Input: 10-690Vac direct input (single model for most services)
- Frequency: 45Hz to 65Hz
- Current Input: 333mV CT Input
- Communications: RS-485 (Modbus RTU or BACnet MS/TP)
- Outputs: Pulse output
- Control Power: 100~415Vac, 50/60Hz; 100~300Vdc
- Operating Temperature: -25¡C to 70¡C (-13¡F to 158¡F)
- Mounting: Integrated TS35 (35mm) DIN rail channel
- Approvals: Measurement Canada approved tamper-proof design
Datasheets
 | AcuRev 1310 DIN Rail Power and Energy Meter Datasheet |
- Mountain Option:
- DIN Rail with LCD Display
- Current Input:
- 333mV
- Meter Model:
- AcuRev 1314
- I/O:
- X0: Base (No Relay)
