The AccuEnergy ACUREV-2110-MV-WEB2 (AcuRev 2110) is a high-density, multi-circuit submeter built for tenant submetering, branch circuit monitoring, and building energy management. It measures up to 18 single-phase circuits (or 6/9 polyphase circuits) from one device, delivers revenue-grade accuracy, and adds WEB2 communications for dual Ethernet, WiFi, and serial RS485 integration. The WEB2 option also expands onboard memory for long-term power and power-quality data logging.

Common Applications

• Tenant submetering and billing
• Branch circuit monitoring for panelboards
• Energy management systems (EMS) integration
• Commercial complexes, malls, hotels, and office buildings
• Apartments and condominiums
• Hospitals, public services, and data centers
• LEED projects and energy reporting

Specifications

• Meter Type: Multi-circuit submeter with real-time data logging and advanced power quality (AcuRev 2110 series)
• Circuits Monitored: Up to 18 single-phase circuits, or 6 (or 9) polyphase circuits
• Current Input (this configuration): mV option supports 333mV and Rogowski coil inputs via SnapOn CT technology
• Nominal current options available on the platform: 80mA, 100mA, 333mV, and RCT Rogowski coil
• Current accuracy: 0.5% full scale
• Voltage Input: Direct voltage measurement up to 400Vac L-N and 690Vac L-L
• VLN range: 10 to 400V
• VLL range: 17 to 692V
• Metering frequency: 45 to 65Hz
• Revenue Grade Accuracy: ANSI C12.20 Class 0.5 and IEC 62053-22 Class 0.5s
• Power Quality: Real-time and logged power quality parameters including THD and harmonics up to the 31st order (voltage and current), plus crest factor, K factor, and unbalance
• Data Logging Memory: 8MB standard. WEB2 option adds 8GB non-volatile memory for storing energy and power quality data
• Communications (this configuration): WEB2 option includes Dual Ethernet, WiFi, and Serial RS485
• RS485 baud rate: 1200 to 115200 bps
• Common protocols supported include Modbus (RTU and TCP/IP), BACnet (IP and MS/TP), SNMP, SNTP, SMTP, MQTT, HTTP/HTTPS Post, and more
• I/O: 18 digital inputs (dry contact), 6 digital outputs, and 2 relay outputs
• Control Power: 100 to 415Vac (50/60Hz) or 100 to 300Vdc. Power consumption: 5W
• Operating Environment: -25¡C to 70¡C. 5% to 95% RH non-condensing

Construction

Datasheets

AcuRev 2100/2110 Multi-Circuit Submeter Datasheet
