AccuEnergy ACUVIM-3-M-5A-P2 : Acuvim-3 Advanced Power Quality Meter, DIN Rail Mount Without LCD, 5A/1A Current Input (Field Selectable), 20-60Vdc Low Voltage DC Control Power (P2)
The AccuEnergy Acuvim-3 Advanced Power Quality Meter is an advanced power quality meter and revenue grade energy meter designed for critical power monitoring and reporting. It is compliant to IEC 61000-4-30 Class A and supports high-accuracy metering with waveform capture, harmonics analysis up to the 127th, onboard data logging, and flexible communications for SCADA, BAS, and industrial power systems. For local viewing, the Acuvim-3 can be paired with the optional remote display module or accessed via a web interface.
Common Applications
- Data centers, UPS systems, and critical infrastructure power monitoring
- Power distribution, substations, and energy management projects
- Industrial automation and manufacturing facility power quality tracking
- DER, microgrids, and virtual power plant performance monitoring
Specifications
- Model Configuration
- Mounting: M (DIN rail mount without LCD)
- Current Input: 5A (5A/1A input, field selectable)
- Aux Power: P2 (20-60Vdc low voltage DC control power)
- Power Quality and Revenue Grade Metering
- Power quality monitoring compliant to IEC 61000-4-30 Class A
- Revenue grade accuracy: IEC 62053-22 Class 0.1S and ANSI C12.20 Class 0.1
- Harmonics measurement up to the 127th
- Logging and Waveform Capture
- Sampling rate up to 1024 samples/cycle
- Waveform capture detection up to 512 samples/cycle, stored in COMTRADE format
- 32 GB onboard data logging with configurable dataloggers
- Communications and Integration
- Multi-protocol support includes IEC 61850, Modbus RTU, Modbus TCP/IP, BACnet IP, BACnet MS/TP, DNP3 TCP, and SNMP
- Interfaces include dual Ethernet, RS485, Wi-Fi, IRIG-B, digital I/O, and USB-C
Construction
| Display | No built-in LCD (DIN rail mount “M” option). Optional remote display module available. |
| Mounting | DIN rail mount installation |
| Current Sensing | 5A / 1A CT input (field selectable) |
| Aux Power | 20-60Vdc low voltage DC control power (P2) |
Datasheets
 |
Acuvim 3 Advanced Power Quality Meter Datasheet |
|
Acuvim 3 Series Power Quality Meter Users Manual |
- Mountain Option:
- DIN rail mount without LCD
- Current Input:
- 5A/1A
- Power Supply:
- 20-60VDC
