Belimo 22PDP-588 : Remote Wet Differential Pressure Transmitter, 0-250, 0-125, 0-50 and 0-25 psid, 10' Cable Harness, Selectable Outputs: 0-5 VDC, 0-10 VDC, 4-20mA, LCD Display, 5-Year Warranty
Specifications
| Voltage AC/DC | AC/DC 24 V |
| Measured Values | Differential pressure |
| Output Signal | 4-20 mA, 0-5 V, 0-10 V |
| Measuring Range Pressure | 0-100 psi |
| Output Voltage [Range] | 1 x 0-5 V, 0-10 V, min. resistance 10 kΩ |
| Output Current [Range] | 1x 4-20 mA, max. resistance 500 Ω |
| Output signal active note | 0-5/10 V or 4-20 mA output, selectable with switch |
| Display Type | LCD |
Datasheets
- Series:
- 22PDP
- Pressure Type:
- Differential
- Media:
- Wet
- Bypass:
- None
- Output Signal:
- 4-20mA, 0-5 VDC, 0-10 VDC
- Display:
- LCD Display
- Enclosure:
- NEMA 4X
- Cable:
- 10' Standard Cable
- Remote Sensors:
- 0-250 PSID
