Belimo AMQB24-MFT : Non Fail-Safe Damper Actuator, 140 in-lb Torque, 120VAC, Programmable (2-10VDC Default) Control Signal, "Q"Quick 7-Second Run Time, 5-Year Warranty
Specifications
| Voltage AC/DC | AC/DC 24 V |
| Power Consumption (Running) | 15 W |
| Power Consumption (Holding) | 1.5 W |
| Power Consumption For Wire Sizing | 26 VA |
| Torque | 140 in-lb [16 Nm] |
| Control Type | MFT/Programmable |
| Direction Of Motion Motor | selectable with switch 0/1 |
| Manual Override | External push button |
| Angle of Rotation | 95 |
| Running Time (Motor) | 7 s / 90° |
| Running Time range (Motor) | 10, 15 or 20 s |
| Protection category | IP54 |
| Degree Of Protection NEMA | NEMA 2 |
| Enclosure Type | UL Enclosure Type 2 |
| Ambient Tempreture | -22...122°F [-30...50°C] |
Datasheets
 | Belimo AMQB24-MFT Technical Data sheet |
| Belimo AMB Series Installation Instructions |
| Belimo Mounting Methods Guide |
| Belimo Master Format |
- Actuator Type:
- Non Fail-Safe
- Torque:
- 180 in-lb
- Voltage:
- 24VAC/DC
- Control Signal:
- MFT Programmable
- Auxillary Switch:
- None
- NEMA 4X Enclosure:
- No
