The Belimo EFCB120-S is a high-torque spring-return (fail-safe) damper actuator delivering 270 in-lb [30 Nm] of torque with two-position on/off control on AC 100-240 V power. It direct-couples to round or square damper shafts up to 1.05 in. with a universal clamp and is a member of the EFB platform for large commercial HVAC dampers that must fail to a safe position. As an EFC fast-acting model it drives to its fail-safe position in about 10 seconds. Two built-in SPDT auxiliary switches signal damper position or interlock equipment.
Specifications sourced from the official Belimo EFCB120-S technical data sheet (rev 2023-03-10).
Overview
Belimo EF-Series actuators are high-torque spring-return drives for large commercial HVAC control dampers requiring fail-safe operation. The EFCB120-S produces 270 in-lb [30 Nm] and mounts directly to round or square damper shafts up to 1.05 in. with its universal clamp (a crank arm and brackets are available for jackshaft and linkage applications). The fail-safe direction is reversible by CW/CCW mounting, and a 5 mm hex crank allows manual positioning. The EFC variant is fast-acting, returning to its fail-safe position in roughly 10 seconds — useful where rapid damper closure matters. Two-position on/off control drives the damper open and the spring returns it on signal or power loss.
Best for
- Applications needing rapid (~10 s) fail-safe damper closure
- Large commercial HVAC dampers needing fail-safe (spring-return) operation
- High-torque damper and louver control (270 in-lb)
- Outdoor-air, mixing-box and economizer dampers that must fail safe
- Line-voltage systems (AC 100-240 V)
- End-position signaling or equipment interlock (2x SPDT)
Key Features
Fast-Acting Fail-Safe
Returns the damper to its fail-safe position in about 10 seconds on power loss — roughly twice as fast as a standard EF actuator, for applications needing rapid closure.
270 in-lb High Torque
Sized for large commercial dampers; direct-couples to round or square damper shafts up to 1.05 in. with a universal clamp.
On/Off Control
Accepts two-position on/off control from a controller, relay or switch.
Reversible Fail-Safe Direction
The spring-return (fail-safe) direction is selectable clockwise or counterclockwise simply by mounting orientation.
Manual Override Crank
A supplied 5 mm hex crank (3/16" Allen) lets you position the damper by hand for setup or service.
Two SPDT Aux Switches
Two built-in SPDT auxiliary switches (1 mA-3 A) signal damper end position or interlock other equipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Belimo |
| Part Number | EFCB120-S |
| Actuator Type | Spring-Return (Fail-Safe) Damper Actuator — fast-acting |
| Nominal Voltage | AC 100-240 V |
| Nominal Frequency | 50/60 Hz |
| Power Consumption (Running) | 9 W |
| Transformer Sizing | 21 VA |
| Torque (Motor & Spring) | 270 in-lb [30 Nm] (minimum, full rotation) |
| Control Signal | On/Off (two-position, 1 or 3-wire) |
| Shaft Range | Up to 1.05 in. [26.7 mm] via universal clamp; crank arm available |
| Angle of Rotation | 95° (adjustable mechanical stops) |
| Running Time (Motor) | 75 s / 90° |
| Spring Return Time | about 10 s (fast-acting) for fail-safe |
| Behavior on Power Loss | Spring returns damper to fail-safe position |
| Fail-Safe Direction | Reversible (CW/CCW) by mounting orientation |
| Auxiliary Switch | 2x SPDT, 1 mA-3 A (0.5 A inductive), DC 5 V-AC 250 V |
| Manual Override | 5 mm hex crank (3/16" Allen), supplied |
| Electrical Connection | 18 AWG plenum cable, 3 ft [1 m], 1/2" NPT conduit connector |
| Overload Protection | Electronic, full 0-95° rotation |
| Electrical Protection | Double insulated (Class 2) |
| Enclosure Rating | NEMA 2 / UL Type 2 |
| Ambient Temperature | -22 to 122°F [-30 to 50°C] |
| Agency Listing | cULus (UL60730-1A/-2-14, CAN/CSA) |
| Quality Standard | ISO 9001 |
| Plenum Rated | UL 2043 (suitable for air plenums) |
| Weight | 12 lb [5.3 kg] |
| Warranty | 5 Years |
Documentation
Related Products
Accessories & Mounting
Common Belimo accessories for mounting, linkage, signaling and powering the EFCB120-S, drawn from the actuator datasheet. All are stocked by ZOT Supply as an authorized Belimo distributor.
Mounting & Linkage
Electrical Add-Ons
Frequently Asked Questions
What is the Belimo EFCB120-S?
The Belimo EFCB120-S is a high-torque spring-return (fail-safe) damper actuator for large commercial HVAC dampers. It produces 270 in-lb [30 Nm] of torque, uses two-position on/off control on AC 100-240 V power, and on power loss its spring drives the damper to a fail-safe position. Its housing is rated NEMA 2.
Is the EFCB120-S a spring-return (fail-safe) actuator?
Yes. The EFCB120-S is spring-return: a mechanical spring drives the damper to its fail-safe position when power or the control signal is lost — no external power is needed to fail safe.
What happens to the EFCB120-S on power loss?
Its internal spring returns the damper to the fail-safe position in about 10 s (fast-acting). The fail-safe direction (CW or CCW) is set by the mounting orientation.
What is the difference between EFC and EF actuators?
EFC actuators are fast-acting: they return to the fail-safe position in about 10 seconds, roughly twice as fast as a standard EF actuator (under 20 seconds). They are otherwise the same 270 in-lb spring-return actuator.
How much torque does the EFCB120-S provide?
It delivers 270 in-lb [30 Nm] of minimum running and spring-return torque, sizing it for large commercial dampers.
What shaft sizes does the EFCB120-S fit?
It direct-couples to round or square damper shafts up to 1.05 in. using its universal clamp. For jackshafts or off-shaft mounting, a crank arm (KH-EFB) and brackets (ZG-120, ZG-JSA-3) are available.
What control signal does the EFCB120-S use?
It uses two-position on/off control. On/Off control is driven from a controller, relay or switch.
Does the EFCB120-S have auxiliary switches?
Yes. It has two built-in SPDT auxiliary switches (rated 1 mA to 3 A) for end-position signaling or interlocking other equipment.
What voltage does the EFCB120-S run on?
The EFCB120-S is a line-voltage actuator running on AC 100-240 V, so no separate 24 V control transformer is required.
How do you manually position the EFCB120-S?
Use the supplied 5 mm hex crank (3/16" Allen) to wind the actuator by hand for setup or service.
Is the Belimo EFCB120-S available from an authorized Belimo distributor?
Yes. ZOT Supply is an authorized Belimo distributor and carries the EFCB120-S. Every unit ships factory new with Belimo's full 5-year warranty and application support.
