The Belimo LMX24-3-F is a compact non-spring-return damper actuator delivering 45 in-lb [5 Nm] of torque with on/off and floating-point control on AC/DC 24 V power. It direct-couples to round or square damper shafts from 1/4 in. to 5/8 in. (up to 3/4 in. with an accessory clamp) and holds its last position on loss of power (it is non-fail-safe, with no spring return), making it part of Belimo's configurable LMX platform for small to mid-size commercial HVAC dampers. A square form-fit coupler lets it drive square jackshafts directly.
Specifications sourced from the official Belimo LMX24-3-F technical data sheet (rev 2026-03-18).
Overview
Belimo LM-Series actuators are compact non-spring-return drives for small and mid-size commercial HVAC dampers — they position the damper under power and hold the last commanded position when power is removed (there is no spring-return fail-safe). The LMX24-3-F produces 45 in-lb [5 Nm] and mounts directly to round or square damper shafts from 1/4 in. to 5/8 in. (up to 3/4 in. with an accessory clamp). Two-position on/off and 3-wire floating-point control position the damper from a controller or switch.
Best for
- Compact non-spring-return damper control where fail-safe return is not required
- Small to mid-size damper and louver positioning (45 in-lb)
- Direct shaft mount, 1/4-5/8 in. (to 3/4 in. with accessory clamp)
- Square jackshaft / form-fit coupling
Key Features
Non-Spring-Return Design
Holds the last commanded position when power is removed (non-fail-safe). Lower cost and power draw than a spring-return actuator where fail-safe operation is not required.
45 in-lb Torque
Sized for small and mid-size dampers; direct-couples to round or square damper shafts from 1/4 in. to 5/8 in. (up to 3/4 in. with an accessory clamp).
On/Off & Floating Point
Accepts two-position on/off or 3-wire floating-point control from a controller, relay or switch.
Square Form-Fit Coupler
Couples directly to square jackshafts with a form-fit adaptor — no round-shaft clamp required.
cULus Listed & Quiet
Double-insulated (Class 2), cULus listed, ISO 9001 built, UL 2043 plenum-rated for long, maintenance-free service.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Belimo |
| Part Number | LMX24-3-F |
| Actuator Type | Non-Spring-Return (Non Fail-Safe) Damper Actuator |
| Nominal Voltage | AC/DC 24 V |
| Nominal Frequency | 50/60 Hz |
| Power Consumption (Running) | 1.5 W |
| Transformer Sizing | 2.5 VA |
| Torque | 45 in-lb [5 Nm] |
| Control Signal | On/Off and Floating Point (3-wire) |
| Shaft Range | 1/4 in. to 5/8 in. (to 3/4 in. with accessory clamp) |
| Angle of Rotation | Max. 95° (adjustable mechanical stop) |
| Running Time (Motor) | 95 s / 90° — factory default; also orderable at 35, 45, 60, 150 s (please specify at time of order) |
| Behavior on Power Loss | Holds last position (non-spring-return) |
| Shaft Coupling | Square form-fit coupler (for square / jackshaft shafts) |
| Manual Override | External push button (self-locking gear) |
| Direction of Motion | Selectable with 0/1 switch |
| Electrical Connection | 18 AWG plenum cable, 3 ft [1 m], 1/2" NPT conduit connector |
| Overload Protection | Electronic, full 0-95° rotation |
| Electrical Protection | Double insulated (Class 2) |
| Enclosure Rating | NEMA 2 / UL Type 2 |
| Ambient Temperature | -22 to 122°F [-30 to 50°C] |
| Agency Listing | cULus (UL60730-1A / -2-14, CAN/CSA) |
| Quality Standard | ISO 9001 |
| Plenum Rated | UL 2043 (suitable for air plenums) |
| Weight | 0.88 lb [0.40 kg] |
| Warranty | 5 Years |
