The Caleffi 523170A is a MixCal+ thermostatic mixing valve with 1-1/4" Male NPT connections, listed to ASSE 1017. It is used for point of distribution temperature control in domestic hot water and hydronic systems.
Best for water heater and storage tank outlets where a single valve sets the distribution temperature for an entire building, zone or riser.
Specifications sourced from Caleffi North America document 01256_NA. Last reviewed August 2026.
Key Features
ASSE 1017 Listed
Certified for point-of-distribution service, controlling water heater outlet temperature for an entire building or zone.
Thermostatic Element Control
A wax-actuated element responds to outlet temperature changes and repositions the shuttle continuously, holding setpoint without power or controls.
Low-Lead Brass Construction
Wetted surfaces carry a weighted average lead content below 0.25%, meeting Section 1417 of the Safe Drinking Water Act.
Technical Specifications
| Connection Size | 1-1/4" |
| Connection Type | Male NPT union |
| Configuration | 3-Way |
| Flow Coefficient (Cv) | 7.6 |
| Recommended flow range | 4.4 - 40 gpm |
| Maximum operating pressure | 200 psi |
| Adjustment temperature range | 95 - 150 °F |
| Maximum inlet temperature | 195 °F |
| Material | DZR low lead brass |
| Certification | ASSE 1017 |
| Series | MixCal+ |
| Valve Technology | Thermostatic |
| Shipping Weight | 7.0 lb |
Documentation
Related Products
- Caleffi 523176A : MixCal+ 3-Way Thermostatic Mixing Valve 1-1/4" Press
- Caleffi 523177A : MixCal+ 3-Way Thermostatic Mixing Valve 1-1/4" Sweat w/ Temp Gauge
- Caleffi 523178A : MixCal+ 3-Way Thermostatic Mixing Valve 1-1/4" Sweat
- Caleffi 523160A : MixCal+ 3-Way Thermostatic Mixing Valve 1" Male NPT
Frequently Asked Questions
Is Caleffi 523170A approved for point-of-distribution service?
Yes. Caleffi 523170A is listed to ASSE 1017, the standard covering temperature-actuated mixing valves used to control hot water distribution from a water heater or storage tank. ASSE 1017 valves regulate system supply temperature; they are not a substitute for ASSE 1070 point-of-use scald protection at individual fixtures.
What is the temperature adjustment range of Caleffi 523170A?
The adjustment temperature range is 95 - 150 °F. Maximum inlet temperature is 195 °F. Confirm the setpoint against the applicable plumbing code for the installation.
What connection does Caleffi 523170A use?
Caleffi 523170A is supplied with 1-1/4" Male NPT connections. Other connection styles in the MixCal+ family are listed under Related Products.
Does Caleffi 523170A include integral check valves?
No. This model is supplied without integral inlet check valves. Caleffi offers a companion model with a C in the product code for applications that require built-in crossflow protection.
What is the warranty on Caleffi 523170A?
Caleffi covers this product under its standard two-year limited warranty against defects in material and workmanship from the date of shipment. ZOT Supply is an authorized Caleffi distributor.
- Product Series:
- MixCal+
- Valve Technology:
- Thermostatic
- Application:
- Point of Distribution
- Connection Type:
- Male NPT
- Connection Size:
- 1-1/4 inch
- ASSE Listing:
- ASSE 1017
- Flow Coefficient:
- 7.6 Cv
- Integral Check Valves:
- No
- Temperature Gauge:
- No
- Adjustment Temperature Range:
- 95 - 150 deg F
- Body Material:
- DZR low lead brass
