Caleffi Z200532 : 2-Way Valve, 3/4" Sweat, 2.5 Cv, 50 psi ΔP (Valve Only)
The Caleffi Z200532 is a Z2 2-way straight valve body designed for use with motorized zone valves. It features a 3/4" sweat connection and straight-through flow pattern, providing reliable on/off hydronic control with minimal pressure loss. Constructed with a stainless steel stem and EPDM rubber seals, the valve delivers long-lasting durability and consistent performance in heating and cooling applications.
Compatible with Caleffi Z1 actuators, the Z200532 is built for residential and commercial hydronic systems requiring dependable zone isolation. Its solid brass body construction ensures corrosion resistance and extended service life.
Key Features
- 2-way on/off, two-position valve body
- Straight-through flow design for smooth operation
- 3/4" sweat connections for soldered installation
- Stainless steel stem with EPDM rubber seals and paddle
- Compatible with Caleffi Z1 actuators
- Durable brass body for hydronic heating and cooling systems
Technical Specifications
- Valve Type: 2-Way Straight
- Connection Type: 3/4" Sweat
- Maximum Operating Pressure: 300 psi
- Maximum ΔP: 50 psi
- Cv Rating: 2.5 gpm
- Medium Temperature Range: 32–240 °F
- Body Material: Brass
Datasheets
 |
|
|
Caleffi Z-One Motorized Zone Valve Installation and Commissioning Manual |
|
|
|
- Valve Pattern:
- 2-Way
- Valve Size:
- 3/4 Inch
- Connection Type:
- Sweat
- CV Rating:
- 2.5
- GPM:
- 5.0 @ 4 psi
- Actuator Type:
- Valve Only
