The Dwyer HFS-2-02 is a stainless steel-body in-line flow monitor that reads 0.2 to 2 GPM (0.75 to 7.5 LPM) of high-pressure fluids through a 1/2 in. female NPT connection, rated to 6000 psig (413 bar) for liquids with ±2% full-scale accuracy.
Flow pushes a sharp-edged floating orifice disk and ring-shaped transfer magnet along a tapered center shaft against a return spring. A magnet follower outside the flow tube tracks the internal magnet, and its red reference line reads flow rate directly on the scale.
Specifications per Dwyer Series HF catalog page 259 (2022-11-29) and Bulletin F-55, FR# 440843-00 Rev. 4 (7/15). Verified October 12, 2026.
Best For
- Heating loop flow
- Setting pressure relief valves
- Fluid handling equipment
- Pulp and paper
- Industrial maintenance
Warranty
Warranty coverage excludes monitor damage caused by excessive contamination. Protect the HFS-2-02 with filtration of at least 74 microns (200 mesh) and clean and inspect it every six months. Contact Team Zot for warranty terms and claims.
Key Features
Floating Orifice Design
A sharp-edged floating orifice disk and transfer magnet ride a tapered center shaft, giving stable variable-area readings at fluid viscosities up to 500 SSU.
Direct-Reading Dual Scale
A magnet follower outside the flow tube carries a red reference line that reads directly against the GPM and LPM scale (0.2 to 2 GPM / 0.75 to 7.5 LPM).
Sealed Metal Casing
All internal wetted parts are sealed inside the tubular body casing. The magnet follower is sealed inside the polycarbonate window tube, so the unit can be washed down with soap and water.
Mount in Any Orientation
Installs horizontally, vertically or inverted with no straight pipe required before or after the monitor. 90° elbows can be fitted on both ends without significant flow variation.
6000 psig Pressure Rating
Rated to 6000 psig (413 bar) for liquid service and 240°F (116°C). Accuracy is ±2% of full scale with ±1% full-scale repeatability.
Stainless Steel High-Pressure Body
Stainless steel casing with FKM seals and PTFE backup, rated to 6000 psig for liquid service.
ZOT Supply is an authorized distributor of Dwyer products.
Technical Specifications
| Model | HFS-2-02 |
|---|---|
| Series | Dwyer Series HF In-Line Flow Monitor |
| Service | High-pressure fluids |
| Flow Range (GPM) | 0.2 to 2 GPM water |
| Flow Range (LPM) | 0.75 to 7.5 LPM water |
| Scale | Dual scale, GPM and LPM, direct reading |
| Connection | 1/2 in. female NPT |
| Body Material | Stainless Steel |
| Wetted Materials | Stainless steel body, FKM (fluoroelastomer) seals with PTFE backup, PTFE-coated Alnico magnet, stainless steel disk |
| Maximum Pressure (Liquids) | 6000 psig (413 bar) |
| Temperature Limit | 240°F (116°C) |
| Maximum Pressure Drop | 5.58 PSID |
| Accuracy | ±2% FS over entire range |
| Repeatability | ±1% of full scale |
| Maximum Viscosity | 500 SSU |
| Specific Gravity Correction | Actual = Observed Reading x √(1.0 / S.G.) |
| Before Use | Units are tested with light hydraulic oil and some oil residue may remain. Check compatibility with your fluid; cleaning may be required before use. |
| Filtration | 74 micron filter or 200 mesh screen minimum |
| Flow Direction | One direction only, matching the arrow on the scale |
| Mounting | Horizontal, vertical or inverted; no straight pipe required |
| Window Tube | Polycarbonate (Lexan) |
| Dimensions | A (reference): 1.875 in.; B (wrench flats): 1.250 in.; C (reference length): 6.562 in. |
| Cartridge Retainer Clip | Waldes No. 5105-12H |
| Shipping Weight | 2 lb (0.9 kg) |
| California Prop 65 | WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
Frequently Asked Questions
What flow range does the Dwyer HFS-2-02 measure?
The HFS-2-02 reads 0.2 to 2 GPM (0.75 to 7.5 LPM) of water on a dual GPM/LPM scale, with ±2% full-scale accuracy and ±1% full-scale repeatability.
What is the maximum pressure rating of the HFS-2-02?
The HFS-2-02 is rated to 6000 psig (413 bar) for liquid service, with a temperature limit of 240°F (116°C).
Does the HFS-2-02 need straight pipe before or after it?
No. The monitor installs directly in the line horizontally, vertically or inverted with no straight pipe required, and 90° elbows can be fitted on both ends without significant flow variation.
How do I correct the HFS-2-02 reading for a fluid with a different specific gravity?
Multiply the observed reading by the square root of (1.0 / S.G.), where S.G. is the specific gravity of your fluid. Indication reads high for heavier fluids and low for lighter fluids.
What filtration does the HFS-2-02 need?
Install system filtration of at least a 74 micron filter or a 200 mesh screen ahead of the monitor. Monitor damage caused by excessive contamination is not covered by warranty.
Can the HFS-2-02 handle reverse flow?
No. Flow must match the arrow on the scale. In the reverse direction the unit acts like a leaky check valve; for occasional reverse flow, install a check valve in parallel with the monitor.
