The Miljoco-Weiss 4CTS-1-160-4L is a Weiss HVAC pressure gauge with a 4-1/2″ dial, a 0-160 psi pressure range and a 1/4″ NPT lower connection.
The Weiss HVAC gauges meet the specifications of contractors in heating, plumbing, air conditioning and ventilating applications.
This series is intended for general service conditions, for pressure or vacuum on air, oil, water, gas or other mediums that do not attack brass.
Specifications on this page are taken from the Weiss General Service Gauges catalog (GSG-4/19). Verified 2026-09-11.
Markets
The manufacturer lists this series for the following applications.
- Heating
- Plumbing
- Air conditioning
- Ventilating
Warranty
Miljoco-Weiss warrants its products to be free from material defects in material and workmanship for 12 months from the date of shipment, or such other period as provided in the product documentation, per the published Miljoco-Weiss terms and conditions of sale (Section 15, Limited Warranty).
Key Features
Lead free wetted parts
Phosphor bronze tube with <0.25% lead free brass socket and lead free solder connection.
UL to NSF/ANSI 372/61
Certified by UL in accordance with NSF/ANSI 372/61.
Accuracy ±1%, Grade 1A
ANSI-ASME B40.1 Grade 1A.
Stainless Steel Case
Drawn stainless steel with push-in Lexan window.
Brass movement
All brass construction with precision gear and pinion.
Technical Specifications
| Model | 4CTS-1-160-4L |
| Type | HVAC pressure gauge, lead free |
| Ordering Code | Series 4CTS-1, range code 160, connection code 4L |
| Range | 0-160 psi |
| Graduations | Figure interval 20 psi, minor graduation 2 psi |
| Dial Size | 4-1/2″ |
| Case | Drawn stainless steel with push-in Lexan window |
| Tube | Phosphor bronze |
| Socket | <0.25% lead free brass |
| Solder Connection | Lead free |
| Dial | White coated metal lithographed with black graduation lines and numerals |
| Movement | All brass construction, precision gear and pinion |
| Pointer | Slotted adjustable |
| Accuracy | ±1% ANSI-ASME B40.1 Grade 1A |
| Connection | 1/4″ NPT lower |
| Certification | UL in accordance with NSF/ANSI 372/61 |
| Operating Temperature | Ambient -40°F to 140°F (-40°C to 60°C); media 180°F (85°C) maximum |
| Dimensions (in.) | A 4.67, B 1.17, E 0.87, L 0.39 |
| Options | Red set hand |
Service note. Steam service gauges should be protected from excessive temperature by the installation of a coil type syphon (Cat. No. SY14-S iron or SY14-B brass).
Source Notes
Source note: Series attribution. 4CTS-1 specifications are taken from the General Service Gauges catalog, where the three HVAC gauge series share a page; the 4CTA-1 and 4CTN-1 submittals identify the other two case descriptions.
Source note: Part number decode. The range and connection segments of this part number are decoded with the Weiss code convention published in the Weiss Stainless Steel Case Gauges catalog To Specify table (numeric code = 0 to that psi, VAC = 0-30 inHg vacuum, V code = 30 inHg vacuum to that psi, 4L = 1/4 in lower, 4B = 1/4 in back); this family's own documents do not print a code table.
Documentation
Related Products
Frequently Asked Questions
What range does the 4CTS-1-160-4L read?
0-160 psi. Figure interval 20 psi, minor graduation 2 psi.
What is the process connection?
1/4″ NPT lower.
How accurate is it?
The published accuracy for this series is ±1% ANSI-ASME B40.1 Grade 1A.
What are the wetted materials?
Tube: Phosphor bronze; Socket: <0.25% lead free brass.
Is there a service warning for this gauge?
Yes. For steam service the manufacturer specifies a coil type syphon (SY14-S iron or SY14-B brass) ahead of the gauge to guard against excessive temperature.
Manufacturer Warranty
Miljoco-Weiss warrants this product to be free from material defects in material and workmanship for 12 months from date of shipment, per the published Miljoco-Weiss terms and conditions of sale.
Warranty service requires written notice of the defect within seven days of discovery. Remedy is repair, replacement or credit at the manufacturer's discretion. Normal wear, corrosion, misuse and unauthorized modification are excluded.
- Type:
- Pressure Gauge
- Series:
- 4CTS-1
- Dial Size:
- 4-1/2 in
- Pressure Range:
- 0-160 psi
- Range Type:
- Pressure
- Connection Size:
- 1/4 in
- Connection Location:
- Lower
- Case Material:
- Stainless Steel
- Wetted Material:
- Lead Free Brass
- Fill:
- Dry
- Accuracy:
- Plus or Minus 1 Percent
