Senva C-2344 : Split-Core 0-10VDC Output Analog Current Sensor, Selectable Ranges: 0-30/60/120A,Output Signal: 0-10VDC, 7-Year Warranty
Senva analog transducers measure AC current and provide a proportional output for load trending and control. Choose from easy to install split-core or compact solid core. Selectable ranges and optional command relay make for a versatile transducer.
APPLICATIONS
- Load trending
- Motor control
- Process control
- Fan/Pump status
- Motor load jamming
- Lighting load levels
Specifications
| Temperature Rating | -15-60 ° C |
| Insulation Class | 600V RMS. For use on insulated conductors only! |
| Insulation Class | Use minimum 75 ° C insulated conductor |
| Frequency Range | 50/60Hz |
Datasheets
 | Senva Analog Current Transducers Data Sheet |
| Senva C-2344 Installation Instructions |
| Buy American Act Certification |
- Mounting Type:
- Split-Core
- Selectable Range:
- 0-30/60/120A
- Output Signal:
- 0-10VDC
