Viconics R850V-8 : Series Step Controllers, 8 Stage Unit Control, Vernier stage: Vdc pulsed: 6 Vdc, 30 mA max.0 to 10 Vdc 5 mA max.
The Viconics R850V series step controller is designed for cost effective, precise modulation of multi- stage control application. An integrated vernier control output will give a precise and full modulation of the load from 0 to 100% of the total capacity.
Specifications
| Operating Temperature | 0°C to 80°C ( 32°F to 176°F ) |
| Operating Humidity | 0 % to 95 % R.H. non-condensing |
| Relay outputs | Isolated relay 30 Vac @ 1.0 amps. max. per output, up to a maximum of 4.0 amps. total per R850 controller. See application note 02. |
| Vernier stage | Vdc pulsed: 6 Vdc, 30 mA max.0 to 10 Vdc 5 mA max. |
| Input impedance | 0 to 10 Vdc into 2Kohms minimum |
| Power Supply | 24 Vac -15%, +10% 50/60 Hz; 4 VA Use a Class 1 ( properly fused ) or Class 2, CSA or UL recognized transformer for power supply & relay outputs. |
Datasheets
 |
Viconics R850V Series Step Controllers Data Sheet |
- Product Category:
- Step Controller
