Belimo F6500HD+SY8-110 : 2-Way 20" Inch Butterfly Valve, ANSI Class Consistent with 125, Cv 27908 + Non Fail-Safe Industrial Valve Actuator, 120VAC, On/Off, Floating Point Control Signal, 2x SPDT, NEMA 4X, 2-Year Warranty
Belimo F6500HD resilient seated butterfly valve assembly with SY8-110 actuator provides dependable flow control for chilled water and hot water HVAC hydronic systems. The actuator supports floating or 3-point control and common building automation sequences. Use the specifications below to confirm pressure class, Cv, voltage, control signal, and enclosure rating before ordering.
Belimo F6500HD Valve Specifications
-
ANSI Class 300 Pattern 2-way Cv 102 Fluid Chilled or hot water, up to 60% glycol, steam Body Pressure Rating ANSI Class 300 End Fitting Flange Valve Size 2" [50] Belimo SY8-110 Valve Actuator Specifications
-
Voltage AC/DC AC 24...240 V / DC 24...125 V Power Consumption (Running) 20 W Power Consumption (Holding) 7 W Power Consumption For Wire Sizing with 24 V 20 VA / with 240 V 52 VA Auxiliary Switches 2x SPDT Control Type BACnet MS/TP Modbus RTU MP-Bus DC 2...10 V DC 0.5...10 V Degree Of Protection NEMA NEMA 4X Enclosure Type UL Enclosure Type 4X
Datasheets
- Valve Pattern:
- 2-Way
- Valve Size:
- 20 Inch
- ANSI Class:
- Consistent with 125
- CV Rating:
- 27908
- Actuator Type:
- Non-Fail Safe
- Voltage:
- 120VAC
- Control Signal:
- On/Off/Floating Point
