ACI A/CTA2-50 : Solid-Core 4-20 mA Output Analog Current Sensor, Selectable Ranges: 0-10/20/50A, Output Signal: 4 to 20 mA (2-Wire, Loop Powered), 5-Year Warranty
Power Up Your Monitoring with the ACI A/CTA2-50: The ACI A/CTA2-50 packs a punch in a compact package, offering accurate and reliable AC current monitoring with a wide range of selectable options.
Key features:
- 4-20 mA output for easy integration into existing systems.
- Selectable ranges (0-10A, 0-20A, 0-50A) for precise monitoring across various applications.
- Solid core construction for cost-effectiveness, lower trip points, and enhanced environmental protection.
- 5-year warranty for lasting confidence in your investment.
Ideal for:
- Load trending and basic power monitoring.
- Monitoring electronic ballasts, computers, data centers, and more.
- Preventative maintenance and project justification (ROI).
- Process control and solid state environments (SCR's).
Upgrade your monitoring capabilities and gain valuable insights with the ACI A/CTA2-50. Contact us today!
Specifications:
| Monitored Current Type | AC Current |
| Maximum AC Voltage | 600 VAC |
| Isolation Voltage | 2200 VAC |
| Core Style | Solid Core |
| Output Signal | Maximum Output Signal: | 4 to 20 mA (2-Wire, Loop Powered) | Limited to 25 mA |
| Aperture Size | 0.75” (19.05 mm) |
| Din Rail Size | 35 mm (U.S. Patent No. 7,416,421) |
| Wiring Connections | 2 Position, Screw Terminal Block (Polarity Sensitive) |
| Wire Recommendations | 2 Conductor (Shielded Cable) |
| Wire Size | 18 to 24 AWG (0.823 mm2 to 0.205 mm2) Copper Wires only |
| Agency Approvals | CE (-RMS Versions): CE to IEC 61326-1: 2012 Class A, UL/CUL US Listed (UL 508) Ind. Control Equipment (File # E309723), RoHS2, WEEE |
Datasheets
 | ACI A/CTA2-50 4-20mA Output Current Sensor Data Sheet |
| ACI 4-20mA Output Current Sensor Installation Instructions |
- Mounting Type:
- Solid-Core
- Selectable Range:
- 0-10/20/50A
- Output Signal:
- 4 to 20 mA
