The Belimo NF24A-MOD is a robust spring-return (fail-safe) damper actuator delivering 90 in-lb [10 Nm] of torque with multi-protocol control over BACnet MS/TP, Modbus RTU and Belimo MP-Bus (plus selectable 0-10/2-10 V analog) on AC/DC 24 V power. It direct-couples to round or square damper shafts up to 1.05 in. with a universal clamp and is a member of the NFB platform for commercial HVAC dampers that must fail to a safe position. On power loss the internal spring drives the damper to its fail-safe position in under 20 seconds.
Specifications sourced from the official Belimo NF24A-MOD technical data sheet (rev 2022-03-15).
Overview
Belimo EF-Series actuators are spring-return drives for commercial HVAC control dampers requiring fail-safe operation. The NF24A-MOD produces 90 in-lb [10 Nm] and mounts directly to round or square damper shafts up to 1.05 in. with its universal clamp (a crank arm and brackets are available for jackshaft and linkage applications). The fail-safe direction is reversible by CW/CCW mounting, and a 5 mm hex crank allows manual positioning. The spring returns the damper to its fail-safe position in under 20 seconds when power is removed. One part number speaks BACnet MS/TP, Modbus RTU and Belimo MP-Bus, and also accepts conventional 0-10 / 2-10 V analog control with 2-10 V feedback; the spring provides fail-safe return.
Best for
- Commercial HVAC dampers needing fail-safe (spring-return) operation
- Medium-torque damper and louver control (90 in-lb)
- Outdoor-air, mixing-box and economizer dampers that must fail safe
Key Features
Spring-Return Fail-Safe
A mechanical spring drives the damper to a safe position on power or signal loss (under 20 seconds), with no external power required to fail safe.
90 in-lb Torque
Sized for mid-size commercial dampers; direct-couples to round or square damper shafts up to 1.05 in. with a universal clamp.
Reversible Fail-Safe Direction
The spring-return (fail-safe) direction is selectable clockwise or counterclockwise simply by mounting orientation.
Manual Override Crank
A supplied 5 mm hex crank (3/16" Allen) lets you position the damper by hand for setup or service.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Belimo |
| Part Number | NF24A-MOD |
| Actuator Type | Spring-Return (Fail-Safe) Damper Actuator |
| Nominal Voltage | AC/DC 24 V |
| Nominal Frequency | 50/60 Hz |
| Power Consumption (Running) | 7 W |
| Torque (Motor & Spring) | 90 in-lb [10 Nm] (minimum, full rotation) |
| Control Type | Communicating — BACnet MS/TP, Modbus RTU, Belimo MP-Bus, or conventional analog |
| Analog Control | 0-10 V / 0-5 V / 2-10 V selectable |
| Position Feedback | 2-10 VDC |
| Shaft Range | Up to 1.05 in. [26.7 mm] via universal clamp; crank arm available |
| Angle of Rotation | 95° (adjustable mechanical stops) |
| Running Time (Motor) | 150 s / 90° |
| Spring Return Time | < 20 s (< 60 s below -22°F) for fail-safe |
| Behavior on Power Loss | Spring returns damper to fail-safe position |
| Fail-Safe Direction | Reversible (CW/CCW) by mounting orientation |
| Manual Override | 5 mm hex crank (3/16" Allen), supplied |
| Electrical Connection | 18 AWG plenum cable, 3 ft [1 m], 1/2" NPT conduit connector |
| Overload Protection | Electronic, full 0-95° rotation |
| Electrical Protection | Double insulated (Class 2) |
| Enclosure Rating | NEMA 2 / UL Type 2 |
| Ambient Temperature | -22 to 122°F [-30 to 50°C] |
| Agency Listing | cULus (UL60730-1A/-2-14, CAN/CSA) |
| Quality Standard | ISO 9001 |
| Plenum Rated | UL 2043 (suitable for air plenums) |
| Weight | 4.6 lb [2.1 kg] |
| Warranty | 5 Years |
Documentation
Accessories & Mounting
Common Belimo accessories for mounting, linkage, signaling and powering the NF24A-MOD, drawn from the actuator datasheet. All are stocked by ZOT Supply as an authorized Belimo distributor.
Mounting & Linkage
Electrical Add-Ons
Frequently Asked Questions
What is the Belimo NF24A-MOD?
The Belimo NF24A-MOD is a robust spring-return (fail-safe) damper actuator for commercial HVAC dampers. It produces 90 in-lb [10 Nm] of torque, uses multi-protocol control (BACnet MS/TP, Modbus RTU, MP-Bus, plus analog) on AC/DC 24 V power, and on power loss its spring drives the damper to a fail-safe position. Its housing is rated NEMA 2.
Is the NF24A-MOD a spring-return (fail-safe) actuator?
Yes. The NF24A-MOD is spring-return: a mechanical spring drives the damper to its fail-safe position when power or the control signal is lost — no external power is needed to fail safe.
What happens to the NF24A-MOD on power loss?
Its internal spring returns the damper to the fail-safe position in < 20 s (< 60 s below -22°F). The fail-safe direction (CW or CCW) is set by the mounting orientation.
How much torque does the NF24A-MOD provide?
It delivers 90 in-lb [10 Nm] of minimum running and spring-return torque, sizing it for mid-size commercial dampers.
What shaft sizes does the NF24A-MOD fit?
It direct-couples to round or square damper shafts up to 1.05 in. using its universal clamp. For jackshafts or off-shaft mounting, a crank arm (KH-AFB) and brackets (ZG-100, ZG-118) are available.
What control signal does the NF24A-MOD use?
It uses multi-protocol control (BACnet MS/TP, Modbus RTU, MP-Bus, plus analog). On/Off control is driven from a controller, relay or switch.
How do you manually position the NF24A-MOD?
Use the supplied 5 mm hex crank (3/16" Allen) to wind the actuator by hand for setup or service.
Is the Belimo NF24A-MOD available from an authorized Belimo distributor?
Yes. ZOT Supply is an authorized Belimo distributor and carries the NF24A-MOD. Every unit ships factory new with Belimo's full 5-year warranty and application support.
