Caleffi Z200413 : 2-Way Valve, 1/2" NPT, 3.5 Cv, 30 psi ΔP (Valve Only)
The Caleffi Z200413 is a Z2 2-way straight valve body engineered for motorized zone valves. It provides reliable on/off control with a straight-through flow path to reduce pressure drop and ensure smooth system operation. The valve features a stainless steel stem with EPDM rubber seals and paddle for long-lasting performance in hydronic heating and cooling systems.
The Z200413 is designed for use with Caleffi Z1 actuators and features 1/2" NPT threaded connections for easy installation. Constructed from durable brass, this valve delivers excellent corrosion resistance and reliable performance in a variety of hydronic system applications.
Key Features
- 2-way on/off, two-position valve body
- Straight-through flow design minimizes pressure drop
- 1/2" NPT threaded connections for secure installation
- Stainless steel stem with EPDM rubber seals and paddle
- Compatible with Caleffi Z1 actuators
- Rugged brass construction for hydronic system reliability
Technical Specifications
- Valve Type: 2-Way Straight
- Connection Type: 1/2" NPT
- Maximum Operating Pressure: 300 psi
- Maximum ΔP: 30 psi
- Cv Rating: 3.5 gpm
- Medium Temperature Range: 32–240 °F
- Body Material: Brass
Datasheets
 | |
| Caleffi Z-One Motorized Zone Valve Installation and Commissioning Manual |
| |
|
- Valve Pattern:
- 2-Way
- Valve Size:
- 1/2 Inch
- Connection Type:
- NPT
- CV Rating:
- 3.5
- GPM:
- 7.0 @ 4 psi
- Actuator Type:
- Valve Only
