Caleffi Z300413 : 3-Way Valve, 1/2" NPT, 3.5 Cv, 30 psi ΔP (Valve Only)
The Caleffi Z300413 is a Z3 3-way diverting valve body for motorized zone valves. It features an on/off two-position operation with a diverting flow pattern, allowing efficient redirection of flow between two outlet ports. Built with a stainless steel stem and EPDM rubber seals and paddle, this valve provides dependable sealing and consistent performance for both heating and cooling applications.
The Z300413 is compatible with Caleffi Z1 actuators and is constructed of durable brass, providing strength, corrosion resistance, and a long service life in hydronic systems.
Key Features
- 3-way on/off, two-position diverting valve body
- Diverting flow pattern for controlled zone redirection
- Stainless steel stem with EPDM rubber seals and paddle
- Compatible with Caleffi Z1 actuators
- Durable brass construction for hydronic system reliability
Technical Specifications
- Valve Type: 3-Way Diverting
- Connection Type: 1/2" NPT
- Maximum Operating Pressure: 300 psi
- Maximum ΔP: 30 psi
- Cv Rating: 3.5 gpm
- Medium Temperature Range: 32–240 °F
- Body Material: Brass
Datasheets
 |
|
|
Caleffi Z-One Motorized Zone Valve Installation and Commissioning Manual |
|
|
|
- Valve Pattern:
- 3-Way
- Valve Size:
- 1/2 Inch
- Connection Type:
- NPT
- CV Rating:
- 3.5
- GPM:
- 7.0 @ 4 psi
- Actuator Type:
- Valve Only
