Caleffi Z200515 : 2-Way Valve, 3/4" NPT, 5.0 Cv, 25 psi ΔP (Valve Only)
The Caleffi Z200515 is a Z2 2-way straight valve body engineered for use with motorized zone valves. It features a 3/4" NPT threaded connection and a straight-through flow path designed for efficient hydronic performance with minimal pressure loss. The valve incorporates a stainless steel stem and EPDM rubber seals to ensure long-lasting reliability and smooth operation.
The Z200515 is compatible with Caleffi Z1 actuators and is ideal for both heating and cooling hydronic applications. Built from durable brass, this valve provides dependable performance and corrosion resistance for residential and commercial system installations.
Key Features
- 2-way on/off, two-position valve body
- Straight-through flow pattern for optimized hydronic performance
- 3/4" NPT threaded connections for quick installation
- Stainless steel stem with EPDM rubber seals and paddle
- Compatible with Caleffi Z1 actuators
- Rugged brass construction for long service life
Technical Specifications
- Valve Type: 2-Way Straight
- Connection Type: 3/4" NPT
- Maximum Operating Pressure: 300 psi
- Maximum ΔP: 25 psi
- Cv Rating: 5.0 gpm
- Medium Temperature Range: 32–240 °F
- Body Material: Brass
Datasheets
 |
|
|
Caleffi Z-One Motorized Zone Valve Installation and Commissioning Manual |
|
|
|
- Valve Pattern:
- 2-Way
- Valve Size:
- 3/4 Inch
- Connection Type:
- NPT
- CV Rating:
- 5.0
- GPM:
- 10.0 @ 4 psi
- Actuator Type:
- Valve Only
