The Dwyer RHPX-3SBA0-00-LCD is a wall mount humidity and temperature transmitter from the Dwyer Series RHPX, built around a capacitive polymer humidity sensor rated to ±3% RH across 10% to 90% RH at 25°C (77°F). Humidity output is field selectable between 4-20 mA, 0-5 V dc and 0-10 V dc, alongside an active analog temperature output on the same selectable range. The bronze sintered filter protects the sensing element in the wall-mounted housing. The housing is UL 94 V-0 rated to IP66 / NEMA Type 4X, and on-board DIP switches select imperial or metric units, voltage or current output, and whether the humidity channel reports relative humidity, dew point, enthalpy or absolute humidity.
- Wall or surface mounted humidity and temperature measurement, with a bronze sintered filter over the sensing element
- Air economizer sequences using the selectable enthalpy or dew point humidity output
- Plenum-space installations covered by UL 2043
- Dwyer publishes these Series RHPX applications: air economizers, outdoor humidity and temperature reference, pool room humidity monitoring, building energy management systems, commercial HVAC systems, clean rooms, museums and data centers
Key Features
Active Analog Temperature Output
Temperature is transmitted on a field-selectable 4-20 mA, 0-5 V dc or 0-10 V dc output from a solid state band gap element accurate to ±0.9°F @ 77°F (±0.5°C @ 25°C).
±3% RH Capacitive Polymer Sensor
Humidity sensor accuracy is ±3% at 10% to 90% RH and 25°C (77°F), across a full 0% to 100% measurement range, with 0.1% RH resolution.
Four Selectable Humidity Metrics
DIP switches 4 and 5 set the humidity channel to relative humidity, enthalpy, dew point or absolute humidity. Absolute humidity spans 0 to 50 g/m3, dew point -75°C to 60°C, and enthalpy -40 to 411 kJ/kg.
Field-Selectable Output and Units
DIP switch 1 selects metric or imperial units, switch 2 selects 0-10 V or 0-5 V, and switch 3 selects voltage or 4-20 mA output. Default is imperial units, 4-20 mA, %RH. On-board trimmers allow ±3.5% RH and ±5°F field offset.
Two-Line Alphanumeric Display
The LCD shows two lines of eight alphanumeric characters, allowing temperature and humidity to be read at the device. Operating range narrows to -20°C to 60°C (-4°F to 140°F) with the display fitted.
UL 2043 Plenum Rated
UL 2043 compliance covers RHPX-XS(B,S,W) wall mount, which includes this model, allowing installation into the plenum space. The unit also carries BTL and CE compliance, and Dwyer qualifies its UL 60335-2-40 listing as meeting UL 60335-2 clause 30.103DV.1 through that same UL 2043 compliance.
Technical Specifications
| Model / SKU | RHPX-3SBA0-00-LCD |
| Sensor Configuration | B — Bronze sintered filter |
| Enclosure Size | S — Small enclosure |
| Humidity Measurement Range | 0% to 100% humidity |
| Humidity Sensor Accuracy | ±3%, at 10% to 90% RH and 25°C (77°F) |
| Humidity Sensor | Capacitive polymer |
| Temperature Measurement Range | -40°C to 60°C (-40°F to 140°F) |
| Humidity Analog Output | 4-20 mA or 0-5 V dc, 0-10 V dc at 5 mA max, field selectable |
| Active Temperature Analog Output | 4-20 mA or 0-5 V dc, 0-10 V dc at 5 mA max, field selectable |
| Active Temperature Accuracy (Solid State Band Gap) | ±0.9°F @ 77°F (±0.5°C @ 25°C) |
| Passive Temperature Sensor | None on this model (order code 0) |
| Power Requirements | 4-20 mA: 10 to 35 Vdc. Voltage output: 15 to 35 Vdc or 15 to 29 Vac |
| Wiring Connection | Removable terminal block, 18 AWG maximum |
| Resolution | Relative humidity 0.1%; temperature 0.1°F/°C; absolute humidity 0.1 g/m3 |
| Additional Calculations | Absolute humidity 0 to 50 g/m3 or 0 to 3000 lb/mmcf; dew point -75°C to 60°C (-102°F to 140°F); enthalpy -40 to 411 kJ/kg or -17 to 177 Btu/lb |
| Operating Temperature Range | -20°C to 60°C (-4°F to 140°F), with LCD |
| Storage Temperature | -30°C to 70°C (-22°F to 158°F), with LCD |
| Display | Two lines of alphanumeric characters, eight characters per line |
| Electrical Entry | 1/2 in NPS thread, cable gland included |
| Enclosure Material | UL 94 V-0 |
| Enclosure Rating | IP66, NEMA Type 4X |
| Product Weight | 170 g (0.38 lb), wall mount |
| Compliance | BTL, CE, UL 2043. UL 60335-2-40 per Dwyer footnote: meets UL 60335-2 clause 30.103DV.1 through UL 2043 compliance. |
| Warranty | 5 year limited warranty |
Documentation
Related Products
Frequently Asked Questions
Reading the Dwyer order code left to right: RHPX is the series, 3 is 3% RH accuracy, S is the small enclosure, B is Bronze sintered filter, A is the selectable analog output, 0 is no passive temperature sensor, and 00 is the cable length option.
Yes. It is fitted with a two-line alphanumeric display, eight characters per line. Note that the operating range narrows to -20°C to 60°C (-4°F to 140°F) with the display fitted.
Yes. DIP switches 4 and 5 set the humidity channel output to relative humidity, enthalpy, dew point or absolute humidity. The default setting is %RH.
It depends on the output mode selected. In 4-20 mA mode the transmitter needs 10 to 35 V dc. In voltage output mode it needs 15 to 35 V dc or 15 to 29 V ac. The 4-20 mA models are not designed for AC voltage operation.
Yes. DS-RHPX Rev.1 lists RHPX-XS(B,S,W) wall mount under its UL 2043 compliance footnote, and RHPX-3SBA0-00-LCD falls in that group.
No. Dwyer states the Series RHPX requires no routine maintenance, is not field serviceable, and cannot be repaired. Field repair should not be attempted and may void the warranty.
5 Year Limited Warranty. The Dwyer Series RHPX carries a five year limited warranty as published on the Dwyer Series RHPX catalog page. Warranty and return handling follow the Terms and Conditions of Sale published by Dwyer Instruments, LLC. Contact customer service for a Return Materials Authorization (RMA) number before shipping any product back for repair, and include a brief description of the problem plus any application notes.
The Series RHPX requires no routine maintenance, is not field serviceable, and cannot be repaired. Field repair should not be attempted and may void the warranty.
ZOT Supply is an authorized DwyerOmega distributor. Warranty support is handled through ZOT Supply at sales@zotsupply.com or 855-825-2811.
