The Belimo LFX24-SR US is a compact spring-return (fail-safe) damper actuator delivering 35 in-lb [4 Nm] of torque with modulating 2-10 VDC control on AC/DC 24 V power. It direct-couples to round damper shafts from 3/8 in. to 1/2 in. (to 3/4 in. with the K6-1 accessory clamp) and, on loss of power, its internal spring returns the damper to a fail-safe position in under 25 seconds, making it part of Belimo's configurable LFX platform for small commercial HVAC dampers that must fail safe.
Specifications sourced from the official Belimo LFX24-SR US technical data sheet (rev 2026-04-09).
Overview
Belimo LF-Series actuators are compact spring-return drives for small commercial HVAC control dampers requiring fail-safe operation. The LFX24-SR US produces 35 in-lb [4 Nm] and mounts directly to round damper shafts from 3/8 in. to 1/2 in. (to 3/4 in. with the K6-1 accessory clamp). On power loss the spring returns the damper to its fail-safe position in under 25 seconds; the fail-safe direction is reversible by CW/CCW mounting. A 2-10 VDC signal (or 4-20 mA with the ZG-R01 resistor) modulates the damper with 2-10 VDC position feedback; the spring provides fail-safe return.
Best for
- Modulating small-damper control with fail-safe return
- Compact damper and zone control (35 in-lb)
- Outdoor-air and exhaust dampers that must fail safe
Key Features
Spring-Return Fail-Safe
A mechanical spring drives the damper to a safe position on power or signal loss (under 25 seconds) — no external power needed to fail safe.
Compact 35 in-lb Actuator
Sized for small dampers; direct-couples to round damper shafts from 3/8 in. to 1/2 in. (to 3/4 in. with the K6-1 accessory clamp).
Modulating 2-10 VDC
Accepts a 2-10 VDC (or 4-20 mA with ZG-R01) signal with 2-10 VDC position feedback.
Reversible Fail-Safe Direction
The spring-return (fail-safe) direction is selectable clockwise or counterclockwise by mounting orientation.
cULus Listed & Quiet
Double-insulated (Class 2), cULus listed, ISO 9001 built and UL 2043 plenum-rated for long, maintenance-free service.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Belimo |
| Part Number | LFX24-SR US |
| Actuator Type | Spring-Return (Fail-Safe) Damper Actuator |
| Nominal Voltage | AC/DC 24 V |
| Nominal Frequency | 50/60 Hz |
| Power Consumption (Running) | 2 W |
| Torque (Motor & Spring) | 35 in-lb [4 Nm] (minimum) |
| Control Signal | Modulating |
| Operating Range (Y) | 2-10 VDC (4-20 mA with ZG-R01 resistor) |
| Position Feedback (U) | 2-10 VDC (max. 0.7 mA) |
| Shaft Range | 3/8 in. to 1/2 in. (to 3/4 in. with K6-1 clamp) |
| Angle of Rotation | 95° (adjustable mechanical stops) |
| Running Time (Motor) | 150 s / 90° |
| Spring Return Time | < 25 s for fail-safe |
| Behavior on Power Loss | Spring returns damper to fail-safe position |
| Fail-Safe Direction | Reversible (CW/CCW) by mounting orientation |
| Electrical Connection | 18 GA plenum cable, 3 ft [1 m], 1/2" NPT conduit connector |
| Overload Protection | Electronic, full 0-95° rotation |
| Electrical Protection | Double insulated (Class 2) |
| Enclosure Rating | NEMA 2 / UL Type 2 |
| Ambient Temperature | -22 to 122°F [-30 to 50°C] |
| Agency Listing | cULus (UL60730-1A/-2-14, CAN/CSA) |
| Quality Standard | ISO 9001 |
| Plenum Rated | UL 2043 (suitable for air plenums) |
| Weight | 3.2 lb [1.5 kg] |
| Warranty | 5 Years |
Documentation
Related Products
Accessories & Mounting
Common Belimo accessories for mounting, linkage, signaling and powering the LFX24-SR US, drawn from the LF actuator datasheet. All are stocked by ZOT Supply as an authorized Belimo distributor.
Mounting & Linkage
Electrical Add-Ons
Frequently Asked Questions
What is the Belimo LFX24-SR US?
The Belimo LFX24-SR US is a compact spring-return (fail-safe) damper actuator for small commercial HVAC dampers. It produces 35 in-lb [4 Nm] of torque, uses modulating 2-10 VDC control on AC/DC 24 V power, and on power loss its spring drives the damper to a fail-safe position in under 25 seconds.
Is the LFX24-SR US a spring-return (fail-safe) actuator?
Yes. A mechanical spring drives the damper to its fail-safe position when power or the control signal is lost — no external power is needed to fail safe.
What happens to the LFX24-SR US on power loss?
Its internal spring returns the damper to the fail-safe position in under 25 seconds. The fail-safe direction (CW or CCW) is set by the mounting orientation.
What shaft sizes does the LFX24-SR US fit?
It direct-couples to round damper shafts from 3/8 in. to 1/2 in. (to 3/4 in. with the K6-1 accessory clamp) using its universal clamp. For shafts up to 3/4 in., use the K6-1 accessory clamp.
What control signal does the LFX24-SR US use?
It uses modulating 2-10 VDC control. The 2-10 VDC input also accepts 4-20 mA with the ZG-R01 resistor and provides 2-10 VDC feedback.
Is the Belimo LFX24-SR US available from an authorized Belimo distributor?
Yes. ZOT Supply is an authorized Belimo distributor and carries the LFX24-SR US. Every unit ships factory new with Belimo's full 5-year warranty and application support.
- Actuator Type:
- Spring-Return (Fail-Safe)
- Torque:
- 35 in-lb
- Control Signal:
- Modulating
- Voltage:
- 24 VAC/DC
- Auxiliary Switch:
- No
- Series:
- LFX
- Feedback Signal:
- 2-10 VDC
