Caleffi Z200683 : 2-Way Valve, 1" G Thread Male Union, 3.5 Cv, 30 psi ΔP (Valve Only)
The Caleffi Z200683 is a Z2 2-way straight valve body designed for motorized zone valves with a male union connection. It features a straight-through flow design for efficient hydronic control and includes 1" G-thread male unions for versatile installation with compatible fittings. Built from brass with a stainless steel stem and EPDM rubber seals, this valve provides exceptional reliability, corrosion resistance, and long service life.
The Z200683 is intended for use with Caleffi Z1 actuators and is suitable for heating and cooling systems requiring durable on/off zone control. Fittings for this valve are available separately—refer to Section 8 Table in Caleffi’s catalog for selection options.
Key Features
- 2-way on/off, two-position valve body
- Straight-through flow pattern for efficient hydronic operation
- 1" G-thread male union connections
- Stainless steel stem with EPDM rubber seals and paddle
- Compatible with Caleffi Z1 actuators
- Brass body for strength and corrosion resistance
- Select compatible fittings from Section 8 Table
Technical Specifications
- Valve Type: 2-Way Straight (Male Union)
- Connection Type: 1" G Thread Male Union
- Maximum Operating Pressure: 300 psi
- Maximum ΔP: 30 psi
- Cv Rating: 3.5 gpm
- Medium Temperature Range: 32–240 °F
- Body Material: Brass
Datasheets
 |
|
|
Caleffi Z-One Motorized Zone Valve Installation and Commissioning Manual |
|
- Valve Pattern:
- 2-Way
- Valve Size:
- 1 Inch
- Connection Type:
- G Thread Male Union
- CV Rating:
- 3.5
- GPM:
- 7.0 @ 4 psi
- Actuator Type:
- Valve Only
